Aiways U5 2022

Usable battery
60 kWh
Nominal battery
63 kWh
Drive
FWD
Real range (combined)
340 km
AC charging
11 kW
DC fast charging
92 kW

Ownership insights

Commute: 340 km real-world range | typical overnight home charging

Road-trip (10-80%): 30 min | +90 km in 10 min | peak 92 kW

Home charging (AC): 11 kW | 0-100% 6 h 10 min

Seats & cargo: 5 seats | 496 L | max 1619 L

Battery warranty: 8 years / 150,000 km

Overview

Aiways U5 2022 overview

In this trim, Aiways U5 2022 is an electric SUV with FWD and seating for 5. WLTP range: 384 km - 410 km, well below the class median of 462 km.

Battery capacity: 60 kWh usable (63 kWh nominal). It runs on a 400 V architecture.

Charging: AC up to 11 kW (Type 2); DC up to 92 kW (CCS Combo 2). For DC fast charging, it adds ~90 km in 10 min; Heat pump: No.

Class comparison

Within a group of 503 SUVs, Aiways U5 2022 leans toward lower peak DC power and less range in 10 min. Peak DC power is below the class median; 92 kW vs 150 kW; 58 kW lower, -39%. Range added in 10 min is lower than the class median; 90 km vs 141 km; 51 km lower, -36%. Usable battery capacity is below the class median; 60 kWh vs 77 kWh; 17 kWh lower, -22%. Worth considering if you can live with lower peak DC power and less range in a 10-minute stop.

Real Range

City - Mild Weather	444 km
City - Cold Weather	327 km
Highway - Mild Weather	310 km
Highway - Cold Weather	238 km

Real range estimates The values shown here are estimates calculated by BEV-Database using WLTP data and the usable battery capacity of the car. Mild weather represents driving in roughly +20 +25 C without heavy use of climate control, while Cold weather reflects winter conditions with cabin heating. Highway assumes steady cruising at about 110 km/h. These figures are not official test results. Real-world range will vary depending on speed, temperature, traffic, road profile, payload, tyres and driving style.

Have questions?

Battery

Nominal Capacity	63 kWh
Usable Capacity	60 kWh
Battery Type	Lithium-ion
Architecture	400 V
Warranty Period	8 years
Warranty Mileage	150000 km
Cathode Material	No Data

Source: Manufacturer

Have questions?

Charging

Home / Destination

Charging Type	Type 2
Port Location	Front Left
Charge Power	11 kW
Charge Time AC (0-100%)	6 h 10 min
Charge Speed (mild)	60 km/h
Charge Speed (cold)	40 km/h

Fast Charging

Fast Charging Port	CCS Combo 2
Port Location	Front Left
Charge Power (max)	92 kW
Charge Power (10-80%)	78 kW
Charge Time DC (10-80%)	30 min
Charge Speed (mild)	490 km/h
Charge Speed (cold)	360 km/h
Autocharge Supported	Yes

Plug & Charge

Plug & Charge Supported	No
Supported Protocol	-

Preconditioning

Preconditioning Possible	No
Automatically using Navigation	No

Have questions?

Performance

Acceleration	7.5 sec (0-100 km/h)
Top Speed	150 km/h
Total Power	150 kW (204 PS)
Total Torque	310 Nm
Consumption	17 kWh/100 km
Drive	FWD

Have questions?

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L Supported	No
Max. Output Power	-
Exterior Outlet(s)	-
Interior Outlet(s)	-

Vehicle-to-Home (V2H)

V2H via AC Supported	No
Max. Output Power	-
V2H via DC Supported	No
Max. Output Power	-

Vehicle-to-Grid (V2G)

V2G via AC Supported	No
Max. Output Power	-
V2G via DC Supported	No
Max. Output Power	-

Have questions?

Energy Consumption

BEVDB model

Combined real range (estimate)	340 km
Combined Energy Use (estimate)	17 kWh/100 km

BEVDB estimates use WLTP-rated (or derived) consumption and usable battery capacity to model city/highway ranges; the combined value averages the four scenarios.

NEDC Real Range

Range	503 km
Rated Consumption	13.8 kWh/100 km

WLTP Ratings (best case)

Range	410 km
Rated Consumption	16.6 kWh/100 km

WLTP Ratings (worst case)

Range	384 km
Rated Consumption	17.4 kWh/100 km

Have questions?

Safety (NCAP)

Safety Rating	3/5
Adult Occupant	73%
Child Occupant	70%
Rating Year	2019
Vulnerable Road Users	45%
Safety Assist	55%

Source: Euro NCAP

Have questions?

Dimensions and Weight

Length	4680 mm
Width	1865 mm
Width with Mirrors	No Data
Height	1700 mm
Wheelbase	2800 mm
Weight Unladen (EU)	1795 kg
Gross Vehicle Weight (GVWR)	2135 kg
Max. Payload	415 kg
Cargo Volume	496 L
Cargo Volume Max	1619 L
Cargo Volume Frunk	0 L
Roof Load	75 kg
Tow Hitch Possible	No Data
Towing Weight Unbraked	No Data
Towing Weight Braked	No Data
Vertical Load Max	No Data

Have questions?

Miscellaneous

Seats	5 people
Isofix	Yes, 2 seats
Turning Circle	No Data
Platform	No Data
EV Dedicated Platform	No Data
Car Body	SUV
Roof Rails	Yes
Heat Pump	No
HP Standard Equipment	-

Reminder: Range and energy consumption figures are estimates. Actual results may vary depending on weather, driving style, terrain, and other conditions.
