Voyah Free 106 kWh 2023

Starting price: €53,990

Specification Road Planner EV Running Cost Calculator EV Garage Planner

Usable battery
100 kWh
Nominal battery
106 kWh
Drive
AWD
Real range (combined)
436 km
AC charging
11 kW
DC fast charging
100 kW

Ownership summary

Verdict:

Voyah Free 106 kWh 2023 fits the role of an AWD electric SUV with a family-first ownership profile for daily driving, road trips and home charging. For ownership planning, the key range numbers are not only 500 km official, but also about 436 km mixed and 326 km in cold highway driving.

In daily use, home charging takes about 10 h 20 min from 0-100%; on trips, the 10-80% DC estimate is about 53 min (est.), so highway use needs more patience. The practical side is documented with 5 seats, 550-1320 L cargo and 8 years / 200,000 km battery warranty. The main caveat is that road-trip charging is slower than newer long-range EVs. Range confidence is high, while specs completeness is mostly complete.

Best fit

Daily drivingRoad tripsHome chargingFamily use

Main caveatRoad-trip charging is slower than newer long-range EVs.

Range reality

Official WLTP range: 500 km
BEVDB mixed estimate: 436 km
Cold highway estimate: 326 km
Official vs BEVDB gap: -64 km / -13%

Charging reality

Home charging: 0-100% 10 h 20 min
Fast charging: 10-80% 53 min (est.)
10-80% range added: 307 km Based on BEVDB combined consumption

Practical ownership

Seats: 5
Cargo: 550-1320 L
Battery warranty: 8 years / 200,000 km

Data quality

Range confidence: High
Specs completeness: Mostly complete
Estimate basis: WLTP data + BEVDB model
Missing key data: Safety rating

Real Range

City - Mild Weather	571 km
City - Cold Weather	361 km
Highway - Mild Weather	413 km
Highway - Cold Weather	326 km

Estimates of actual range. The values given here are BEVDB estimates calculated from WLTP data and usable battery capacity, based on the BEVDB model. The BEVDB real-range card uses four fixed reference scenarios: City (Mild), Highway (Mild), City (Cold), and Highway (Cold). Mild means +20°C (70°F) without intensive climate-control use; cold means -10°C (14°F) with cabin heating. City speed is 50 km/h (30 mph), and highway speed is 110 km/h (70 mph). These figures are not official test results. Actual range will vary depending on speed, temperature, road conditions, road profile, load, tires, and driving style.

Have questions about Real Range?

Battery

Nominal Capacity	106 kWh
Usable Capacity	100 kWh
Battery Type	Lithium-ion
Architecture	400 V
Warranty Period	8 years
Warranty Mileage	200000 km
Cathode Material	NCM

Source: Manufacturer

Have questions about Battery?

Charging

Home / Destination

Charging Type	Type 2
Port Location	Rear Left
Charge Power	11 kW
Charge Time AC (0-100%)	10 h 20 min
Charge Speed (mild)	50 km/h
Charge Speed (cold)	30 km/h

Fast Charging

Fast Charging Port	CCS Combo 2
Port Location	Rear Left
Charge Power (max)	100 kW
Charge Power (10-80%)	80 kW
Charge Time DC (10-80%)	53 min
Charge Speed (mild)	380 km/h
Charge Speed (cold)	280 km/h
Autocharge Supported	No Data

Plug & Charge

Plug & Charge Supported	No
Supported Protocol	-

Preconditioning

Preconditioning Possible	No
Automatically using Navigation	No

Have questions about Charging?

Charging Times

Home / destination charging — 0–100%

AC full charge: fastest ~10h 20m

Charging option	Power used	Approx. time	Range per hour	Notes
Wall plug · 230V / 10A	2.3 kW	49h 25m	10 km/h	—
1-phase 16A · 230V / 16A	3.7 kW	30h 45m	16 km/h	—
1-phase 32A · 230V / 32A	7.4 kW	15h 20m	31 km/h	—
3-phase 16A · 400V / 3x16A	11 kW	10h 20m	46 km/h	—
3-phase 32A · 400V / 3x32A	11 kW	10h 20m	46 km/h	Limited by vehicle

Fast charging — 10–80%

Fastest DC 10–80%: ~53 min

Charging option	Power used	Approx. time	Range per hour	Notes
CCS 50 kWCCS connector	50 kW avg.	1h 25m	240 km/h	—
CCS 150+ kWCCS connector	80 kW avg.	53 min	383 km/h	Vehicle-limited above 150 kW

Estimated charging times are based on usable battery capacity, charging power and vehicle charging limits. Peak DC power is usually reached only briefly; average 10–80% power is more useful for estimating real charging time. Actual charging speed can vary by charger output, battery temperature, state of charge, weather, software and battery condition.

Performance

Acceleration	4.4 sec (0-100 km/h)
Top Speed	200 km/h
Total Power	360 kW (489 PS)
Total Torque	720 Nm
Drive	AWD

Have questions about Performance?

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L Supported	No
Max. Output Power	-
Exterior Outlet(s)	-
Interior Outlet(s)	-

Vehicle-to-Home (V2H)

V2H via AC Supported	No
Max. Output Power	-
V2H via DC Supported	No
Max. Output Power	-

Vehicle-to-Grid (V2G)

V2G via AC Supported	No
Max. Output Power	-
V2G via DC Supported	No
Max. Output Power	-

Have questions about Bidirectional Charging?

Energy Consumption

BEVDB model

Combined real range (estimate)	436 km
Combined Energy Use (estimate)	22.8 kWh/100 km

BEVDB estimates use WLTP-rated (or derived; falls back to NEDC when WLTP is missing) consumption and usable battery capacity to model city/highway ranges; the combined value is a weighted mix of city/highway and mild/cold scenarios. See the methodology and data sources for inputs, official source boundaries, fallback rules, and versioning.

WLTP Ratings (worst case)

Range	500 km
Rated Consumption	20.2 kWh/100 km

Have questions about Energy Consumption?

Safety (NCAP)

Safety Rating	No Data
Adult Occupant	No Data
Child Occupant	No Data
Rating Year	No Data
Vulnerable Road Users	No Data
Safety Assist	No Data

Have questions about Safety?

Dimensions and Weight

Length	4905 mm
Width	1950 mm
Width with Mirrors	No Data
Height	1645 mm
Wheelbase	2960 mm
Weight Unladen (EU)	2415 kg
Gross Vehicle Weight (GVWR)	2945 kg
Max. Payload	605 kg
Cargo Volume	550 L
Cargo Volume Max	1320 L
Cargo Volume Frunk	72 L
Roof Load	75 kg
Tow Hitch Possible	Yes
Towing Weight Unbraked	750 kg
Towing Weight Braked	2000 kg
Vertical Load Max	No Data

Have questions about Dimensions and Weight?

Miscellaneous

Price	€53,990
Seats	5 people
Isofix	Yes, 2 seats
Turning Circle	11.5 m
Platform	DONGFENG ESSA
EV Dedicated Platform	No
Car Body	SUV
Roof Rails	Yes
Heat Pump	No
HP Standard Equipment	-

Reminder: Range and energy consumption figures are estimates. Actual results may vary depending on weather, driving style, terrain, and other conditions. Review the BEVDB methodology for estimate boundaries and source labels. If this model page looks wrong, use Contact and include this page URL plus an official source link when possible.
