Jeep Compass Electric 74 kWh 2025

Usable battery
74 kWh
Nominal battery
80 kWh
Drive
FWD
Real range (combined)
407 km
AC charging
11 kW
DC fast charging
160 kW

Ownership insights

Commute: 407 km real-world range | typical overnight home charging

Road-trip (10-80%): 35 min | +152 km in 10 min | peak 160 kW

Home charging (AC): 11 kW | 0-100% 7 h 40 min

Seats & cargo: 5 seats | 550 L

Battery warranty: 8 years / 160,000 km

Overview

Jeep Compass Electric 74 kWh 2025 overview

Jeep Compass Electric 74 kWh 2025 comes as an electric SUV with FWD and 5 seats. Energy use is 17.5 kWh/100 km, slightly lower than the class median of 17.9 kWh/100 km.

BEVDB real-world estimate is around 286 km in cold highway driving. Battery: 74 kWh usable (80 kWh nominal).

Charging includes AC charging up to 11 kW (Type 2); DC fast charging up to 160 kW (CCS Combo 2). For a typical DC stop, it adds ~152 km in 10 min; Cargo volume is 550 L.

Class comparison

Compared with 503 other SUVs, Jeep Compass Electric 74 kWh 2025 leans toward slower acceleration and longer range. 0–100 km/h is slower than the class median; 8.5 s vs 6.6 s; 1.9 s slower, +29%. WLTP range is above the class median; 500 km vs 461 km; 39 km higher, +8%. A strong match for longer stints between charges, with slower acceleration as the main trade-off.

Real Range

City - Mild Weather	548 km
City - Cold Weather	392 km
Highway - Mild Weather	371 km
Highway - Cold Weather	286 km

Real range estimates The values shown here are estimates calculated by BEV-Database using WLTP data and the usable battery capacity of the car. Mild weather represents driving in roughly +20 +25 C without heavy use of climate control, while Cold weather reflects winter conditions with cabin heating. Highway assumes steady cruising at about 110 km/h. These figures are not official test results. Real-world range will vary depending on speed, temperature, traffic, road profile, payload, tyres and driving style.

Have questions?

Battery

Nominal Capacity	80 kWh
Usable Capacity	74 kWh
Battery Type	Lithium-ion
Architecture	400 V
Warranty Period	8 years
Warranty Mileage	160000 km
Cathode Material	NCM

Source: Manufacturer

Have questions?

Charging

Home / Destination

Charging Type	Type 2
Port Location	Rear Left
Charge Power	11 kW
Charge Time AC (0-100%)	7 h 40 min
Charge Speed (mild)	60 km/h
Charge Speed (cold)	40 km/h

Fast Charging

Fast Charging Port	CCS Combo 2
Port Location	Rear Left
Charge Power (max)	160 kW
Charge Power (10-80%)	90 kW
Charge Time DC (10-80%)	35 min
Charge Speed (mild)	550 km/h
Charge Speed (cold)	400 km/h
Autocharge Supported	Yes

Plug & Charge

Plug & Charge Supported	No
Supported Protocol	-

Preconditioning

Preconditioning Possible	No Data
Automatically using Navigation	No Data

Have questions?

Performance

Acceleration	8.5 sec (0-100 km/h)
Top Speed	180 km/h
Total Power	157 kW (213 PS)
Total Torque	345 Nm
Consumption	17.5 kWh/100 km
Drive	FWD

Have questions?

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L Supported	No
Max. Output Power	-
Exterior Outlet(s)	-
Interior Outlet(s)	-

Vehicle-to-Home (V2H)

V2H via AC Supported	No
Max. Output Power	-
V2H via DC Supported	No
Max. Output Power	-

Vehicle-to-Grid (V2G)

V2G via AC Supported	No
Max. Output Power	-
V2G via DC Supported	No
Max. Output Power	-

Have questions?

Energy Consumption

BEVDB model

Combined real range (estimate)	407 km
Combined Energy Use (estimate)	17.5 kWh/100 km

BEVDB estimates use WLTP-rated (or derived) consumption and usable battery capacity to model city/highway ranges; the combined value averages the four scenarios.

WLTP Ratings (best case)

Range	500 km
Rated Consumption	17.5 kWh/100 km

WLTP Ratings (worst case)

Range	500 km
Rated Consumption	17.5 kWh/100 km

Have questions?

Safety (NCAP)

Safety Rating	No Data
Adult Occupant	No Data
Child Occupant	No Data
Rating Year	No Data
Vulnerable Road Users	No Data
Safety Assist	No Data

Source: Euro NCAP

Have questions?

Dimensions and Weight

Length	4552 mm
Width	1928 mm
Width with Mirrors	No Data
Height	1675 mm
Wheelbase	2795 mm
Weight Unladen (EU)	2198 kg
Gross Vehicle Weight (GVWR)	No Data
Max. Payload	No Data
Cargo Volume	550 L
Cargo Volume Max	No Data
Cargo Volume Frunk	No Data
Roof Load	No Data
Tow Hitch Possible	Yes
Towing Weight Unbraked	750 kg
Towing Weight Braked	1000 kg
Vertical Load Max	No Data

Have questions?

Miscellaneous

Seats	5 people
Isofix	No Data
Turning Circle	No Data
Platform	STLA MEDIUM
EV Dedicated Platform	No
Car Body	SUV
Roof Rails	Yes
Heat Pump	Yes
HP Standard Equipment	No, optional

Reminder: Range and energy consumption figures are estimates. Actual results may vary depending on weather, driving style, terrain, and other conditions.
